InssTek X KARI C-103 1ton Rocket Nozzle …
- [ Firing Test - C-103 Radiative Cooled Nozzle Extension ]
- InssTek X KARI 1ton Rocket Nozzle Extension
- - We printed a "1ton Rocket Nozzle Extension" with our research partner, Korea Aerospcae Research Institute (KARI).
- - The nozzle extension was manufactured with C-103 (Nb-based Alloy) by InssTek`s DED Process
- - C-103 manufacturing process was conducted in an atmospheric environment.
- - The firing test of the C-103 nozzle extension confirmed the possibility of C-103 manufacturing using DED Process.
- [Model info.]
- - Size : (Diameter) 150mm, (Height) 75mm
- - Thickness : 1mm
- - Material : C-103 (Nb-based Alloy)
- - Printing Time : 10 hours
- * 3D Printing was conducted in an atmospheric environment
-
InssTek X KARI 3-ton Multi-Material Rock…
- - InssTek printed a "Multi-Material 3-ton Rocket Nozzle" with our research partner, Korea Aerospcae Research Institute (KARI).
- - The first firing test of the multi-material rocket nozzle confirmed the possibility, and the second test(20sec) verified the performance of the rocket nozzle.
- - This rocket nozzle consists of 2 different materials. The inner part with cooling channel is made with Al-Bronze(Cu based Alloy), and the outer part is made with Inconel 625(Ni based Alloy).
- [Model info.]
- - Size: D 280 mm, H 257 mm
- - Material: Inconel 625 (Outer) Al-Bronze (Inner)
- - Cooling channel: Length 1.7mm, Width 1.0mm
- - Fabrication video: https://lnkd.in/g8RsgmTM
-
NARAE - Large Scale Robot 3D Printing Sy…
- - The NARAE project is a system for manufacturing large scale part of space industry
- - InssTek's precise CVM(Clogged Vibration Method) powder feeding system is combined with robot arms.
- - We successfully made a 1m+ scale rocket nozzle in 12days.
- - NARAE system is continously updated and will be completed next year (The final system can produce maximum 8m height parts.)
-
InssTek X KARI 3-ton Multi-Material Rock…
- World's First Multi-Material Rocket Nozzle Firing Test
- - We printed a "multi-material 3-ton rocket nozzle" with our research partner, Korea Aerospace Research Institute (KARI).
- - The first firing test of the multi-material rocket nozzle was successfully conducted. Various tests for verification will be continued.
- - We propose an advanced technology for aerospace parts, utilizing the characteristics of each material.
- - This rocket nozzle consists of 2 different materials. The inside of the cooling channel is made with Al-Bronze(Cu-based Alloy), and the outside of the cooling channel is made with Inconel 625(Ni-based Alloy).
- [Model info.]
- - Size: D 280 mm, H 257 mm
- - Material: Inconel 625 (Outer) Al-Bronze (Inner)
- - Cooling channel: Length 1.7mm, Width 1.0mm
- - Fabrication video: https://lnkd.in/g8RsgmTM
-
Multi Material Rocket Nozzle CT Scanning
- Analysis of Multi Material Rocket Nozzles using CT Scanning
- Analysis of rocket nozzle was conducted to check how well it is manufactured.
- CT Scanning was proceed to find the internal defects (ex. cracks, pores...) and there was no defects inside of rocket nozzle and it shows fully dense combining of two materials. Also we have checked cooling channel is precisely manufactured for entire parts.
- With this, InssTek's combination of hardware and software technology shows fully dense multi material parts can be manuafactured.
-
Highlights of InssTek's 2022 Activities
- 2022 was a busy year for us with lots of events such as technology developments, new research, and attended broad wide exhibitions.
- Thank you for making InssTek a success, we will do our best for the best.
-
KARI 3ton Rocket nozzle full-scale fabri…
- Full-scale fabrication for propulsion validation
- Size: D 280mm H 257mm
- Material: Inconel625 (Outer) Al-Bronze (Inner)
- Printing time: 300H
- Fabricated by InssTek's MX-Fab with PCM-Multi
-
New DMT Technology LFM-2
- New Technology Zoom Optics & Moving Vision
- Zoom Optics
- Zoom Opic type AM-Module is the key solution to improve process efficiency and deposition quality. Since the lens magnification can be controlled with software, it is possible to change the lens magnification value during deposition.
- DMT Moving Vision
- The vision parts move vertically to increase the degree of shape freedom while maintaining optimal quality by continuously applying DMT technology. InssTek's simultaneous 5-Axis AM-CAM predicts the expected point of collision between the vision parts and the printed part and operates the vision part to avoid it.
- Video demonstrates the LFM-2 operation and how it works in your projects.
-
Porous Coating by MX-Med
- "Porous Coating by MX-Med"
- ▶ Key Feature
- - MiXO Pro (5-Axis CAM Software)
- - MX-Med (Porous Coating Machine with Dual Module)
- - PCM-Single (CVM Powder Feeding System)
- Porous Coating was performed on two hip cup implants simultaneously by installing two modules in one machine.
-
Industrial application of white metal(ve…
- Industrial application of white metal (ver.2)
- - Material: Carbon steel (Base), White metal (layer)
- - Beam size: SDM1200
- - Printing time: 2.5h (3layer)
-
ICAM2022(ESA) InssTek
- InssTek presented on the topic Additive Manufacturing - Process Development III at ICAM2022 on Thursday, March 10th, 14:00(CET):
- Multi-Material Rocket Nozzle Manufacturing Process – From Materials Research to Manufacturing with Direct Energy Deposition(DED)
- It was an opportunity to explain the technical difference between DED technology and the rocket nozzle manufacturing process
- to show the possibility of developing more applications in the aerospace industry.
-
Multi-Material Rocket Nozzle(Full Ver.)
- A full video of the multi-material rocket nozzle manufacturing process!
- At the 1st International Conference on Advanced Manufacturing(ICAM) hosted by ESA and NASA,
- InssTek presented "Multi-Material Rocket Nozzle Manufacturing Process
- – From Material Research to Fabrication with DED(Direct Energy Deposition)" on the topic.
- In the future, DED technology will greatly contribute to the space industry,
- and check out InssTek's technological differentiation through the multi-material rocket nozzle video.
-
Industrial application of white metal
- The white metals are any of several light-colored alloys used in the base as well as for things like bearings.
- Especially It has a low coefficient of friction and is used as a lining material for bearings.
- - Application: Shaft-Bush Bearing (Cladding on Base Plate)
- - Base Material: Carbon Steel
- - Printed Material: White Metal
- - Size(mm): Outer - 170 / Inner - 130 / Length - 120
- - Printing Time: 1 hour
- This is a case in which applied for prototype testing to it is easy to manufacture and repair, so laser cladding on bearing inner metal.
-
New way to Fabricate
- We are preparing a massive printing volume through multi-robot printing.
- This project will be a new way for additive manufacturing in the future.
- - Multi-Robot printing
- - Massive printing volume
- - Real-Time Feedback
- Please look forward to the ongoing project.
- Coming soon!
-
Multi-Material Rocket Nozzle
- We have completed the production of a multi-material rocket nozzle.
- - Material : Nimonic75(90%), IN718(Outer) + Al-Bronze(Cooling Channel & Inner)
- - Size : Width - 420mm(Top)/382mm(Bottom), Height - 552mm
- - Machine used : MX-1000 (SDM2400)
- - Production period : 200hr
- It wasn't easy to print but completed without trial and error with the efforts of many staff and our stable technology.
- In the future, expect InssTek to make a significant contribution to the aerospace industry and take a leap forward.
- A full video of the production process will be released later.
- See you soon!
- The difference is Value.
-
Metal AM(Additive Manufacturing) Technol…
- COMTES FHT specializes in applied research of metallic materials dealing with developments in the field of additive technologies at the experimental workplace.
- For research, Technologies and machines used DED (Directed Energy Deposition) metal 3D printer.
- The InssTek's MX-600 uses the Powder blown method, in which a powder that is entrained by an inert gas is injected into a laser-exposed area and used primarily for research purposes to advance the field of additive technology.
- ▶ https://www.comtesfht.com/additive-manufacturing
-
Repeatability Test for MX-Lab
- Repeatability Test for MX-Lab
- (Comparing Composition Change of 5 FGM Sample Made in Parallel)
- This experiment is about MX-Lab’s Repeatability.
- For your reliable research, Repeatability is very important.
- The component analysis of five Stellite6 + SS316L FGM(Functionally Graded Material) samples stacked at once shows a similar compositional distribution.
- Through this test, we confirmed that the feeder of MX-Lab can supply and control powder consistently.
-
InssTek AMPM2021 conference
- InssTek participated in the AMPM2021 conference on 8:50am June 23(UTC-5:00), hosted by Orlando, Florida.
- ☞ SESSION A22 Alloy Design & Development
- 243 - NiCoMoTiAl High Entropy Alloying in DED/Additive Manufacturing Process:
- Investigation the Potential of CVM Powder Feeding System for Rapid Alloy Scanning
-
InssTek 5Axis AM-CAM Feature
- Features of InssTek 5Axis AM-CAM
- - Path Optimization
- - Multi Material
- - Automatic Pipe
- - Serial & Parallel Tool Path
- - Simulation function
-
New Generation DED Technology (Multi Mat…
- About Insstek
- InssTek Technology
- Case Study - Multi Material DED Technology
- Powder Feeder for Additive Manufacturing
- Summary
-
New product launch !! MX-Fab1
- All-In-One System for Fabrication
- Easiest Installation
- Efficient Inert Gas Control System
- Accurate Feeding System
- Multi Material Fabrication
-
InssTek company introduction IR video
- DMT metal AM technology specialist InssTek.
- Meet the new generation of Additive Manufacturing.
- High functional component production.
- Re-modeling, repairing and special coating.
- We are breaking the limits of Additive Manufacturing.
-
See how it is easy to design new High-En…
- Easy to change element
- Use pure powder
- More than 5 elements
- Easy to change ratio
- Accurate feeder
-
Material Designer for MX-Lab
- Want to make a new material?
- Material researchers
- Fast and effective testing
- Users inexperienced with CAD
-
Multi material valve project
- Project Name : Multi Material Valve Project
- Material Description : Inconel 625(Inner), SUS316(Outer)
- Manufacturing Device : InssTek’s MX-1000
-
Rocket Fuel Tank Project
- Application : Rocket Fuel Tank Project
- Material Description : Ti-6AI-4V
- Powder Size : 53-150um
- Manufacturing Device : MX-1000 (InssTek)
-
New Product Launch "MX-Lab
- New Product Launch "MX-Lab
- - CVM Hexa-Powder Feeding System
- - Specialized for Material Research
- - Remarkable User Experience
- - Desktop Alloy Maker
-
InssTek’s 1st Open House event
- InssTek, Inc which is global metal 3D printer manufacturer held 1st Open hosue event on 29th October. InssTek introduced InssTek's accumulated 3D metal printing technology as DED(Direct Energe Deposition) method and new generation model "MX-Lab"
-
Mx Lab Introduction
- Creative Additive Manufacturing machine in DMT Technology enables the most precise accurate metal powder feeding.
