Media

Media List

A Faster Way to Create High Entropy Alloys and Other Advance…

In this interview, industry expert Chulyong Sim explores groundbreaking advancements in high entropy alloy development, highlighting new methods that can drastically reduce production time and enhance material performance for aerospace, automotive, and defense applications among others. What are high entropy alloys and why are they important? High entropy alloys are materials made up of five or more elements, each within an atomic ratio of 5-35%. They generally form a single-phase crystal structure, or they can be characterized by a nearly equal composition entropy basis with an entropy array greater than 1.6 R at room temperature. Unlike conventional alloys, high entropy alloys do not form intermetallic compounds due to high entropy effects. Instead, the elements form a solid solution, leading to severe lattice distortion. This results in excellent strength, hardness, corrosion resistance, and oxidation resistance. This makes high entropy alloys highly functional materials with broad industrial applications. What are the challenges in developing high entropy alloys? Despite their advantages, high entropy alloys are difficult to develop. While industrial demand for high entropy alloys is rising, the conventional methods of creating them are slow, inefficient, and require extensive post-processing. The two main methods are: Alloy powder method – This involves atomization, but requires additional post-processing. Mixing powder method – This uses a ball milling process but also demands secondary processes like spark plasma sintering or compaction. Both methods take days or even weeks to create and test new high entropy alloys. The trial-and-error approach is time-consuming and makes it hard to iterate on new material compositions quickly. How does InssTek’s new methodology improve high entropy alloy development? We have developed a disruptive technology that dramatically shortens and simplifies the high entropy alloy creation process. Our clogged vibration method (CVM) powder feeding system enables the real-time modification of alloy compositions during direct energy deposition (DED) 3D printing. Instead of restarting the entire process for every composition change, our system allows adjustments on the fly, reducing the time required from weeks to just a few hours per iteration. Our CVM powder feeding system consists of six powder feeder blocks that operate individually or together. This allows for: - Single-material deposition by activating one feeder - Dual-material deposition by activating two feeders - Multi-material deposition by simultaneously controlling up to six different powders We have successfully demonstrated stable powder delivery at 0.03 grams per minute over a continuous seven-hour operation - an industry first. What role does the MX-Lab play in your methodology? Alongside our CVM system, we developed MX-Lab, a core software tool called Material Designer to streamline high entropy alloy research. This software offers an all-in-one solution for material scientists, allowing them to: Design sample geometry and alloy compositions seamlessly Generate NC code files for 3D printing with a single click The MX-Lab and CVM system together enable rapid alloy scanning, meaning we can explore new material properties faster than ever before. Additionally, the MX-Lab has an Auto Z feature, which automatically adjusts the laser focusing distance to maintain precise energy density during material deposition. What was the process for testing and validating your high entropy alloy samples? To validate our high entropy alloy development approach, we employed direct energy deposition additive manufacturing (DED-AM) using our CVM powder feeding system. We designed a combinatorial alloy map to explore various compositions and developed nine different high entropy alloy specimens for testing. Each sample underwent rigorous analysis using advanced characterization techniques. Scanning Electron Microscopy (SEM) and Energy Dispersive X-ray Spectroscopy (EDS) were used to confirm element distribution within the samples, ensuring uniformity and stability. X-ray Diffraction (XRD) allowed us to verify that the specimens had successfully formed a face-centered cubic (FCC) single-phase structure, an essential characteristic for maintaining desirable mechanical properties. We also conducted Differential Scanning Calorimetry (DSC) to measure the solvus temperature of the alloys, which reached an impressive 1202 °C, exceeding the standard temperature range observed in traditional high entropy alloys. Among the nine specimens produced, one exhibited the most stable gamma-gamma prime phase and demonstrated superior high-temperature properties, making it a strong candidate for further industrial applications. How efficient is your method compared to traditional approaches? Our CVM powder feeding system, in combination with the MX-Lab software, significantly enhances the efficiency of high entropy alloy development by reducing production time and material waste. The entire process of producing a full nine-sample batch was completed in just 4 hours and 20 minutes. This included 60 minutes dedicated to setting up stacking conditions, 20 minutes for modeling and parameter adjustments, and 180 minutes for the direct energy deposition (DED) stacking process of all nine specimens. In contrast, traditional methods can take weeks to produce and test a single high entropy alloy sample due to the need for repeated iterations and extensive post-processing. By eliminating these inefficiencies, our methodology accelerates research and development and lowers costs by minimizing material usage. This breakthrough represents a major shift in how high entropy alloys can be designed, tested, and optimized, making it possible to explore a wider range of compositions in a fraction of the time previously required. What are the main applications driving demand for high entropy alloys? High entropy alloys are particularly valuable for high-temperature applications, which represent approximately 65.5% of 3D printing use cases. Industries such as aerospace, automotive, defence, and power generation benefit significantly from the superior properties of high entropy alloys. In aerospace, these materials are used for turbine blades and engine components that require outstanding oxidation resistance at extreme temperatures. In the automotive industry, they are ideal for parts that must endure significant thermal stress and mechanical fatigue, improving both performance and longevity. Defence and power generation applications also rely on high entropy alloys for their exceptional corrosion and heat resistance, making them essential for long-term durability in harsh environments. One of the most notable applications is in nickel-based superalloys, which contain a reinforced gamma-prime phase that enhances mechanical strength, oxidation resistance, and corrosion resistance even at temperatures exceeding 1000 °C. This ability to withstand extreme conditions makes high entropy alloys indispensable in industries where material performance under stress is critical. Beyond high entropy alloys, what other material innovations can your technology support? While our technology has been instrumental in advancing high entropy alloy research, its capabilities extend beyond these materials. Our system is also well-suited for the development of metal matrix composites (MMCs), which combine metals with ceramic or reinforcing materials to enhance mechanical properties such as strength, wear resistance, and thermal stability. Our CVM powder feeding system and MX-Lab software enable the fabrication of functionally graded materials (FGMs), which are designed with a gradual variation in composition and properties, making them ideal for aerospace and biomedical applications. The ability to control multi-material deposition with precision allows researchers and engineers to create custom material compositions tailored to specific industrial needs. By leveraging these advanced capabilities, we are opening up infinite possibilities in material science, accelerating research and commercial applications across multiple fields.

3D News - Metal Printing InssTek Revolutionizes 3D Material …

Anexo3D, a leading channel specializing in 3D printing, has featured InssTek's MX-Lab! https://youtu.be/LZvKnsx8SMg If you would like to learn more about InssTek's MX-Lab, click the link below to find out more. [Machine Info] https://insstek.com/products/mx-lab [Research Cases] https://insstek.com/casestudy/mxlab_research #Metallurgy #Alloying #MultiMaterial #HighEntropyAlloys #Superalloy #MetalMatrixComposite #FunctionallyGradedMaterial #FGM #HEA #MMC #RapidAlloy

Modern Technology Brings New Speed to Alloy Development

Modern materials research technology is dramatically enhancing traditional metallurgical techniques, making rapid alloy development more efficient than ever. This advancement addresses persistent challenges in materials testing, significantly reducing resource requirements and shortening development timelines in advanced materials research. Modern Alloy Development Technology Traditional metallurgical research methods have historically demanded substantial resources for alloy composition testing. Conventional casting-based processes often require over 10 kg of material per test specimen and involve multiple complex steps, including melting, mold preparation, casting, and machining. This traditional approach typically takes two to three weeks to evaluate a single alloy composition. Rapid Material Testing Process Advanced materials research equipment has significantly improved the standard approach to alloy development. The latest metallurgical research technology, illustrated by InssTek's MX-Lab system, is extremely efficient in rapid alloy testing. This advanced system reduces specimen material requirements to less than 0.1 kg and completes the process in just an hour, dramatically streamlining new alloy development. Advanced Metallurgical Research Applications Modern alloy research methods made possible by this technology go far beyond simple efficiency improvements. With the ability to handle six different metal powders simultaneously, this equipment expands the possibilities for materials science research. This advanced capability supports a range of sophisticated applications, including precise composition control for high entropy alloy (HEA) development, metal matrix composite (MMC) research using multiple powder materials, functionally graded material (FGM) development for specialized applications, and in-situ alloying studies for creating novel materials. Transformative Research Methodology This advancement in materials research technology represents a major shift in metallurgical testing methods. The rapid alloy development process eliminates many of the time-consuming steps required by traditional approaches. While conventional materials testing involves lengthy preparation and processing, modern equipment enables direct specimen production through advanced manufacturing techniques, significantly streamlining the research process. Improved Research Efficiency The significance of the materials research technology is felt throughout the alloy development cycle. Researchers may now undertake detailed composition testing on a wider range of materials, thus broadening the field of metallurgical study. These enhanced testing capabilities enable a deeper investigation of material properties and performance characteristics, accelerating the pace of materials innovation. Future of Material Research The rapid alloy development process has wide-ranging implications across various research fields. The ability to efficiently test different material combinations accelerates materials science research, particularly in industries that demand specialized alloy compositions, such as aerospace and energy. This shift in metallurgical research methods signals a future where materials testing becomes both more sophisticated and efficient. With reduced resource requirements and faster development cycles, researchers can explore methodologies that were once impractical—potentially leading to significant breakthroughs in advanced materials development.

New Approaches to Metal Matrix Composite (MMC) Development

Advanced materials research equipment is changing the way manufacturers approach metal matrix composite (MMC) development. Recent tests using InssTek's MX-Lab technology have demonstrated exceptional capabilities in manufacturing aluminum-ceramic composites, achieving wear resistance properties that surpass those of standard aluminum alloys. Advanced Manufacturing Capabilities The study in question highlights MX-Lab's advanced Directed Energy Deposition (DED) technique for processing various aluminum-based materials. The research equipment showcased remarkable versatility, successfully producing pure aluminum, aluminum alloy series 4000 and 6000, and aluminum-ceramic metal matrix composites. This demonstrates its capability to handle a diverse range of material combinations within a single manufacturing platform. Research Methodology Innovation MX-Lab's precision manufacturing capabilities enabled researchers to undertake comprehensive wear testing using a uniform ball-on-disc technique. The testing conditions were precisely controlled at 5 kgf load, 30-minute duration, and 50 rpm rotation speed, confirming the equipment's capability to produce consistent, high-quality test specimens from a variety of material combinations. Superior Performance Results The research equipment's ability to manufacture metal matrix composites produced particularly excellent results. Wear tests demonstrated that MMC specimens created with the MX-Lab method had significantly higher wear resistance when compared to traditional materials. The aluminum-ceramic composite exhibited a remarkably low wear amount of 0.0106 g, surpassing pure aluminum (0.0408 g) and standard aluminum alloys (0.0394 g for 4000 series, 0.1092 g for 6000 series). Notably, the friction coefficient was comparable to that of typical aluminum alloys, showing no compromise in operational properties. Manufacturing Technology Advancement This study highlights MX-Lab's important contribution to enhancing production capabilities in the field of metal matrix composites. The system's ability to precisely control material deposition allows for the development of complicated material combinations while ensuring consistent material characteristics throughout the manufactured components. Research Equipment Innovation The successful production of high-performance aluminum-ceramic composites underscores MX-Lab's advanced processing capabilities. Its ability to work with both metallic and ceramic materials while ensuring precise control over the manufacturing process marks a significant advancement in materials research technology. Future Research Applications The demonstrated capabilities of MX-Lab in processing advanced material combinations point to new opportunities for materials research and development. This technology platform gives researchers additional tools for investigating novel material combinations and manufacturing techniques, notably in the field of wear-resistant components.

Specialized Software Drives Advances in Alloy Development

The development of specialized software tailored for alloy design and specimen preparation is driving a major shift in material science. InssTek's Material Designer software enhances how researchers create and refine material research specimens, particularly for multi-material applications. Transforming Materials Research Methodology Traditionally, preparing test specimens has required extensive knowledge of both material science and complex design software. However, the rise of specialized material design software is simplifying this process, offering researchers a more efficient approach to specimen preparation. This innovation reduces design complexity while maintaining precise control over material compositions. Advanced Material Composition Control The software's ability to manipulate up to six different materials at once is a big step forward in multi-material design technology. This powerful control system allows researchers to precisely create specimens for a wide range of material studies, including high entropy alloys (HEA), functionally graded materials (FGM), and metal matrix composites (MMC), without requiring deep understanding of typical 3D design software. Research Efficiency Enhancement What traditionally required many software tools and considerable technical expertise can now be achieved with a single, integrated platform. The material design program simplifies the specimen preparation procedure, allowing researchers to focus on their experimental goals rather than the complexities of specimen design. This efficiency in specimen preparation leads directly to accelerated research timelines. Integrated Research Workflow The Material Designer software integrates seamlessly with InssTek's MX-Lab system, offering a comprehensive solution for materials research. This integration ensures that test specimens are produced with precision, strictly adhering to research specifications while maintaining tight control over material compositions from design to production. Practical Applications in Materials Science The program proves particularly useful in complex material research scenarios. When producing high entropy alloys, researchers can accurately control the distribution and composition of multiple components. For functionally graded materials, the approach allows for precise specification of material transition, while metal matrix composite development benefits from precise control over reinforcement distribution. Future Research Implications The implications of this advanced material design software go beyond current applications. As materials research explores increasingly complex compositions and structures, the ability to efficiently design and prepare specimens becomes even more critical. This software platform establishes a foundation for future advancements in automated materials research and high-throughput experimentation.

Addressing Long-Standing Challenges in Reactive Metal Proces…

A major advancement in materials research equipment is reshaping how scientists approach reactive metal processing. InssTek's MX-Lab, featuring a unique auto-purging system, provides new opportunities for researchers working with oxygen-sensitive materials, effectively addressing long-standing challenges in reactive metal research. Reactive Metal Research Challenges Materials scientists have long faced significant obstacles when developing alloys that incorporate reactive metals. These materials are highly susceptible to oxidation at high temperatures, making research complex and requiring extensive, costly infrastructure. This limitation has been particularly impactful in the development of advanced alloys, where precise atmospheric control is critical to preserving material integrity. Advanced Auto-Purging Technology MX-Lab's advanced auto-purging system marks an important breakthrough in materials research equipment design. This innovative technique offers impressively rapid atmospheric control, lowering oxygen levels to less than 50 ppm in just 17 minutes. This rapid production of inert conditions allows researchers to move forward with material processing while reducing the danger of oxidation-related issues. Atmospheric Control Performance The auto purging system's performance goes beyond the initial atmospheric conditioning. Throughout the research process, the system maintains constant oxygen levels by automatically altering inert gas flow rates to optimize consumption while ensuring consistent ambient conditions. This sophisticated control system is especially useful during prolonged research sessions, where maintaining constant settings is vital for achieving reliable results. Research Equipment Innovation This development represents a major shift in how laboratories handle reactive metal processing. MX-Lab’s integrated auto-purging feature eliminates the need for separate atmospheric control devices, streamlining workflows and reducing setup complexity. By incorporating advanced purging technology directly into the equipment, this system sets a new standard for materials science instrumentation Enhanced Research Capabilities MX-Lab's auto-purging capability considerably improves materials science research opportunities. Researchers can now confidently work with highly reactive metals and research novel alloy compositions that were previously difficult to study. This capability is particularly useful for developing new materials for advanced applications that require precise control over processing conditions. Future Research Applications This innovative research equipment technology has far-reaching consequences for materials science. As the field investigates more complex material systems, MX-Lab's advanced atmospheric control capabilities lay the groundwork for future breakthroughs in alloy development and materials processing.

A Smarter Approach to Metal Manufacturing with New DED Techn…

Comprehensive research conducted using InssTek's directed energy deposition (DED) technology has resulted in significant advances in manufacturing capabilities. The study, which compared DED-manufactured components to traditionally processed materials, demonstrates how modern manufacturing technology is reshaping approaches to metal processing. Advancing Metal Manufacturing Technology InssTek's adoption of DED manufacturing methods has led to significant advancements in metal processing technologies. Research shows that this technology effectively treats a wide range of metals, including iron, titanium, nickel, and niobium-based materials, achieving mechanical properties that match or exceed those of traditional casting and forging methods. Research Methodology and Findings The comprehensive study adhered to strict ASTM testing requirements to guarantee an objective comparison between DED-manufactured components and conventionally processed materials. The results provided intriguing insights into material performance. Titanium components made using InssTek's DED method, for example, displayed remarkable mechanical qualities that matched or exceeded those of their traditionally manufactured counterparts. Material Performance Validation The thorough examination of the test findings demonstrates the consistency and dependability of the DED manufacturing process. The research revealed outstanding performance across a variety of material types: Nickel-based alloys produced with DED had exceptional strength, while niobium components demonstrated outstanding structural integrity. These findings are extremely important for industries that need high-performance materials, such as aerospace and advanced engineering applications. Manufacturing Process Innovation InssTek's DED technology marks a big step forward in how manufacturers approach metal processing. Unlike existing technologies, which frequently require costly post-processing and have geometric complexity constraints, DED technology allows for precise control over material characteristics while maintaining manufacturing efficiency. Industrial Implementation Benefits These research findings have significant implications for the manufacturing sector. The proven performance of DED-processed materials opens new possibilities for industries that require high-performance components. This technology is especially valuable in applications where traditional manufacturing methods may fall short in meeting specific material requirements or producing complex geometries. Future Manufacturing Applications The success of this study suggests that DED technology has even broader potential in metal manufacturing. As industries push for more advanced material properties and intricate component designs, InssTek's DED technology stands out as a key solution for meeting these evolving manufacturing demands.

New Metal Joining Technology Solves Rocket Propulsion Challe…

The successful integration of C103 niobium alloy and Ti-6Al-4V titanium alloy within singular aerospace components represents key progress in dissimilar metal joining technology. This development in multi-material manufacturing resolves a key issue in aerospace applications, particularly in rocket propulsion systems where various component sections demand unique material characteristics. Advancing Dissimilar Metal Integration Joining dissimilar metals has limited aerospace component manufacturing, which requires specific materials for different parts. Historical manufacturing approaches require complex assembly procedures when parts must incorporate materials due to their unique characteristics. However, recent advancements in material bonding technology have enabled the seamless integration of materials with considerably different properties within a single part. Multi-Material Manufacturing Innovation Integrating C103 niobium alloy with Ti-6Al-4V represents an especially significant accomplishment in aerospace materials technology. Using sophisticated directed energy deposition, the manufacturing process shows outstanding precision in controlling the interface between these dissimilar metals. This precision becomes particularly important in use cases like rocket nozzle manufacturing, where parts should continue to operate in extreme operational settings. The success of this metal integration process is built upon the careful control of material characteristics throughout the manufacturing sequence. The process parameters have been maximized to enable robust metallurgical bonding between the C103 sections, renowned for their outstanding performance at high temperatures, and the Ti-6Al-4V areas, valued for their superior strength-to-weight properties. Material Integration Technology Development Comprehensive analysis of the bimetallic parts has unveiled outstanding bonding properties between the dissimilar metals. The manufacturing process preserves the unique advantages of each material, including the superior high-temperature and creep resistance of C103 niobium alloy and the superior mechanical characteristics and corrosion resistance of Ti-6Al-4V titanium alloy. This dissimilar metal joining process’s success relies heavily on exact powder control throughout the manufacturing process. The process parameters have been carefully improved to deal with the two materials’ diverse powder properties, with powder sizes carefully regulated to guarantee a high degree of material deposition and bonding throughout the component. Aerospace Applications and Implications This development in multi-material manufacturing technology has broad implications for the design and production of aerospace components. The potential to create seamless transitions between dissimilar metals within a single part enables new possibilities for maximizing material characteristics in crucial aerospace use cases. The successful production of a small-size rocket nozzle showcases the practical use of this technology in real-world aerospace components. The consequences of this material integration technology go beyond immediate use cases in rocket propulsion systems. The ability to merge materials with diverse characteristics in a single manufacturing process indicates novel possibilities for component design over multiple aerospace applications, potentially eradicating the need for complicated assembly processes and increasing overall component performance.

Accelerating Superalloy Development with Directed Energy Dep…

Scientists at the Korea Advanced Institute of Science and Technology (KAIST) have made a major breakthrough in superalloy development by using sophisticated materials research tools. The research, available in Materials & Design, shows how directed energy deposition technology facilitates rapid screening and development of novel Ni-Co-based superalloys with outstanding thermal stability and specific yield stress. Revolutionizing Superalloy Development Developing novel superalloys has historically been a time-consuming process that requires extensive casting trials and testing. However, scientists have significantly sped up the process with InssTek's MX-Lab, an advanced materials research system with six independent powder feeders. The system's distinct abilities enabled the rapid production and screening of 50 diverse superalloy compositions, shortening the usual development timeline by eight times in comparison to conventional casting techniques. Advanced Research Methodology The research approach demonstrates the advanced abilities of contemporary materials research tools. The MX-Lab's multi-powder feeding system facilitates precise control over the composition of every test sample, enabling scientists to simultaneously work with elemental powders, including nickel, cobalt, titanium, aluminum, and molybdenum. Such a level of control enables the development of sophisticated alloy compositions with unparalleled precision and efficiency. The system's directed energy deposition technology has proven particularly effective for generating test specimens that precisely represent the final alloy’s microstructural features. Scientists were able to accurately control the formation of γ/γ' microstructures, which are critical for the high-temperature performance of superalloys. Material Performance Validation The research tools’ abilities made comprehensive material testing and validation possible. The newly developed Ni-Co-based superalloys showcased outstanding thermal stability at temperatures up to 1000°C, with extensive microstructural analysis demonstrating stable γ' phase distributions even after extended exposure to high temperatures. The alloy known as AM_33 demonstrated a γ' solvus temperature of 1202°C and maintained outstanding microstructural stability throughout long-term thermal exposure tests. The material's specific yield stress performance maintained its competitive edge with, and in some cases outperformed, established commercial superalloys over a broad spectrum of temperatures. Research Equipment Innovation The materials research system's ability to maintain close control over powder mixing ratios proved critical for achieving consistent outcomes across many test specimens. The tool’s advanced monitoring systems enabled scientists to maintain tight control over processing parameters during the study, enabling reproducible outcomes across all of the test samples. Future Implications for Materials Research This step forward in rapid alloy development showcases the high potential of advanced materials research tools for speeding up the discovery and optimization of novel materials. The capability to quickly screen many alloy compositions while controlling material features enables novel possibilities for developing high-performance materials for aerospace and energy use cases. The success of this research methodology paves the way for potential use cases beyond superalloys, enabling novel methods for developing multiple advanced materials where precise composition control and rapid iteration are critical for success. References and Further Reading Yoo, B., et al. (2024). Novel Ni–Co-based superalloys with high thermal stability and specific yield stress discovered by directed energy deposition. Materials & Design, 238, pp.112607–112607. https://doi.org/10.1016/j.matdes.2023.112607.
